VPSA Oxygen Plant

 /Factory OEM/ODM VPSA Oxygen Generation Unit Industrial Use Oxigen Producing Generator Supplier
Vpsa Oxygen Generation Vpsa Oxygen Generation Vpsa Oxygen Generation Vpsa Oxygen Generation Vpsa Oxygen Generation

Factory OEM/ODM VPSA Oxygen Generation Unit Industrial Use Oxigen Producing Generator Supplier

Technical Specifications

1、Oxygen Output: 50-7500 Nm³/h

2、Oxygen Purity: 28-94%

3、Oxygen Pressure: 0.015-2 MPa

4、Oxygen Dew Point: ≤-45°C



5、Soundproofing: ≤75dB at 1 meter outside the plant

  • Brand:

    BANGWIN

  • Item no.:

    BW

  • Product origin:

    China

  • Lead Time:

    90
Inquiry now
  • Product Detail

Working principle

Based on the principle of pressure swing adsorption, zeolite molecular sieve is used as the adsorbent. Due to the selective adsorption properties of zeolite molecular sieve, nitrogen is adsorbed in large quantities by the zeolite molecular sieve, and oxygen is enriched in the gas phase. Under the action of pressure swing adsorption, nitrogen and oxygen separation is achieved. The process uses two adsorption towers: one tower adsorbs and produces oxygen, and the other tower desorbs and regenerates under negative pressure. The opening and closing of the pneumatic valve is controlled by a PLC intelligent program, so that the two towers cycle alternately and continuously produce high-quality oxygen.



Technical Features

  1. High-performance pneumatic valves utilize high-frequency cylinders; imported Metso positioners; SMC solenoid valves and quick-opening valves; lifespans exceeding 3 million cycles;
  2.
  3. PLC intelligent program controller for easy operation and stable operation;
  4.
  5. Patented air flow distribution system significantly improves adsorption efficiency;
  6.
  7. Airbag-type compression device prevents molecular sieve pulverization;
  8.
  9. Unique blizzard-style filling method for more uniform distribution;
  10.
  12. Power consumption per cubic meter of pure oxygen can reach as low as 0.28 kW/h.
  13.

VPSA Oxygen Generator Key Technical Parameters: 80% Purity

Model Specifications
HL-500
 HL-1000 HL-2000 HL-3000 HL-4500 HL-6250 HL-7500
Gas Production (Nm/h) 500 1000 2000 3000 4500 6250 7500
Voltage(kv) 10 10 10 10 10 10 10
Installed Power (KW) 250 435 715 1120 1600 2240 2500
Valve Air Consumption (m³/min) 1.0 1.5 2.0 3.0 5.0 6.0 6.5
Cooling Water Circulation (m³/h) 20 40 80 110 120 130 140
Soft Water Consumption (m³/h) 1.92 2.7 2.88 3.9 4.2 4.5 4.8



VPSA Oxygen Generator Key Technical Parameters: 93% Purity

Model Specifications HL-200 HL-300 HL-400 HL-500 HL-600 HL-800 HL-1000
Gas Production (Nm/h) 200 300 400 500 600 800 1000
Voltage 380v 380v 380v 380v 380v 10kv 10kv
Installed Power (KW) 120 165 200 270 317 380 450
Valve Air Consumption (m³/min) 0.5 0.7 0.9 1.1 1.4 1.6 2.0
Cooling Water Circulation (m³/h) 11 15 20 26 30 38 55
Soft Water Consumption (m³/h) 1.2 1.8 1.98 2.1 2.1 2.4 2.7



VPSA Oxygen Generator Key Technical Parameters: 93% Purity

Model Specifications HL-1200 HL-1600 HL-2000 HL-3000 HL-3600 HL-4500 HL-5500
Gas Production (Nm/h) 1200 1600 2000 3000 3600 4500 5500
Voltage(kv) 10 10 10 10 10 10 10
Installed Power (KW) 565 715 1000 1250 1600 2000 2500
Valve Air Consumption (m³/min) 2.0 2.4 3.0 3.3 4.2 5.5 6.5
Cooling Water Circulation (m³/h) 62 90 100 110 120 130 140
Soft Water Consumption (m³/h) 2.7 2.88 3.3 3.6 4.2 4.5 4.8
